Chapter 18 Applied Model Building Tutorial: Penobscot Mercury Exposure Model (P-MEM)

⬇ Download this chapter

This chapter demonstrates how every submodel introduced in this library — schooling, landward and seaward migration, selective tidal stream transport, osmoregulation, metabolism, digestion, foraging, migration cue detection, and contaminant exposure — can be assembled into a single site-specific agent-based model. The Penobscot Mercury Exposure Model (P-MEM) is the applied implementation provided in Quintana (2026), and hosted GitHub Version Repository. Unlike the tutorial examples in Chapters 15 and 16, P-MEM is spatially and temporally explicit: agents navigate a 2-D GIS representation of the Penobscot River Estuary, forced by hourly hydrodynamic outputs from a validated Delft3D FM model, with a nested agent-based time step representing one 5-minute interval on a real calendar beginning in April 2023.

Results from the full model — spatial exposure maps, time-series outputs, and multi-scenario comparisons — are available in the interactive Mercury Risk Explorer.

18.1 Module Integration

P-MEM couples hydrology, behavior, and physiology in a single model time step. Contaminant exposure in estuaries is spatially and temporally heterogeneous, structured by tidal forcing and seasonal discharge that simultaneously organize anadromous fish migration timing and the spatial distribution of methylmercury (MeHg) in the water column. Realized exposure risk — defined as the cumulative contaminant interaction accumulated by an individual over time — is not determined by spatial coincidence between contamination and habitat suitability alone, but by what the fish is doing, where it is, and what physiological state it is in at every time step.

The model simulates two focal species: alewives (Alosa pseudoharengus) as obligate spawning migrants, and striped bass (Morone saxatilis) as facultative seasonal predators. These species interact through predator–prey encounters that modify alewife movement (fleeing) and change which exposure pathways dominate. Predation pressure is varied across scenarios by scaling striped bass visual detection distance, which modifies encounter rates without changing population size.

Temporal structure. Each time step represents one 5-minute interval. The calendar advances minute → hour → day using the calendar procedure. Hydrodynamic patch variables (velocity, depth, salinity, temperature, SPM) are updated every 12 time steps (1 hour) from the empirical time-series loaded at setup, derrived from the outputs of a hydrodynamic model. Migration cue detection (update-migration-cue) runs once per day. All behavioral, physiological, and exposure submodels run every tick for active agents.

Spatial scale. The model domain is the Penobscot River Estuary, Maine, discretized as a 0–200 × 0–350 patch grid (3 m per patch, set with resize-world 0 200 0 350). Patches are classified as upper estuary, middle estuary, lower estuary, and sea using GIS shapefiles. The dam (Milford Dam) is located at y = 342 and serves as both a behavioral barrier and a validation cross-section. home-patch (upper estuary, patch 199 346) and migration-patch (sea entry, patch 100 35) are fixed.

Coupling logic.

The complete behavioral workflow and decision-making structure implemented within the agent-based model, including state-dependent movement, environmental cue evaluation, physiological feedbacks, and transitions among behavioral submodels.
The complete behavioral workflow and decision-making structure implemented within the agent-based model, including state-dependent movement, environmental cue evaluation, physiological feedbacks, and transitions among behavioral submodels.

The core tick sequence within penobscot-go is:

  1. Update patch data from hydrodynamic time series (update-patch-data)
  2. Reset cost-to-home, cost-to-sea, cost-to-prey routing fields
  3. Per-agent migration cue accumulation (calc-migration-probability)
  4. Per-agent behavioral sequence — calculate-metabolism → swim → mercury-contamination → methylmercury-contamination → osmoregulate → digest → forage
  5. Residence phase and departure logic (wait-days counter)
  6. Dam crossing and estuary entry/exit counters (count-alewives)
  7. Export results (export-results)

The swim procedure is the central integrator: it sets previous-patch / previous-x / previous-y, calls calculate-cost-to-home → calculate-difficulty-landward → calculate-swimming-speed-landward → selective-tidal-stream-transport-landward (which calls migrate-landward, which calls school), and then deducts calculate-swim-energy. All of this happens before contamination tracking, osmoregulation, or digestion, because movement determines which patch the agent is on when those exposure functions read patch-level contaminant values.

18.2 Function Dependencies

The table below shows the full dependency chain for an alewife in the landward migration phase. Functions are listed in the order they must be called each tick.

Function Required Inputs Output Variables Dependent On
calendar ticks, minute, hour, day minute, hour, day, month, night? tick counter
update-patch-data current-hour, velocity-series, salinity-series, temp-series, spm-series velocity, salinity, temperature, SPM (per patch) calendar (hourly)
update-migration-cue day, cue-days cue-active?, migration-trigger? calendar (daily)
calc-migration-probability migration-trigger?, migration-probability migration-probability, start-migration? update-migration-cue
calculate-metabolism weight, temperature, age-num, met-base, optimal-temperature metabolism-rate, swim-efficiency, osmoregulation-efficiency patch temperature
calculate-cost-to-home home-patch, patch-terrain, difficulty-factor cost-to-home (all water patches) swim-efficiency
calculate-difficulty-landward velocity, weight, max-seaward-velocity, max-landward-velocity difficulty-factor patch velocity
calculate-swimming-speed-landward energy, difficulty-factor, max-speed, min-speed, velocity, prev-speed, swim-efficiency speed, prev-speed calculate-difficulty-landward
selective-tidal-stream-transport-landward velocity, speed, min-speed, swim-efficiency, selective-tidal-transport?, STST-start-tick xcor, ycor, selective-tidal-transport?, tidal-transport-in-patch calculate-swimming-speed-landward
migrate-landward (inside STST Case 3) speed, home-patch, cost-to-home, schooling coefficients xcor, ycor, trail, heading, patch visit counters calculate-cost-to-home, schooling state
calculate-swim-energy difficulty-factor, swim-efficiency, swim-base E-swim, energy after movement
mercury-contamination mercury, SPM, metabolism-rate, ionregulatory-stress, min-Hg, max-Hg hg-uptake-risk, hg-exposure-total, hg-exposure-duration swim, patch position
methylmercury-contamination methylmercury, SPM, metabolism-rate, ionregulatory-stress, min-MeHg, max-MeHg mehg-uptake-risk, mehg-exposure-total, mehg-exposure-duration swim, patch position
osmoregulate salinity, acclimated-salinity, chloride-cell-density, E-base, E-creation ionregulatory-stress, chloride-cell-density, E-osmo, energy patch salinity, metabolism-rate
digest stomach-contents, digestion-rate, digestion-efficiency stomach-contents, energy, weight, mehg-foraging-total forage (prior tick)
forage energy, landward-migration?, weight, original-weight, salinity, SPM foraging?, lipid-loss?, filter-feed?, energy, weight, stomach-contents swim, osmoregulate
count-alewives previous-patch, patch-here, patchtype daily totals (dam crossings, estuary entry/exit) end of tick
export-results all agent and patch state variables CSV output files end of tick

Key dependency on swim: All contamination, osmoregulation, and digestion functions read patch-level variables (mercury, methylmercury, salinity, temperature, SPM) from patch-here. This means swim — which moves the agent — must complete before any of these functions run. If the order is reversed, agents are exposed to the contaminant levels of the previous tick’s patch, not their current location.

STST and schooling coupling: selective-tidal-stream-transport-landward gates the call to migrate-landward. migrate-landward contains the full schooling sequence (find-schoolmates → find-nearest-neighbor → separate / cohere + align → adjust-speed) before executing path-following movement. Agents in STST drift passively and do not school; this is correct behavior and means school cohesion metrics are only meaningful for active-swimming ticks.

Migration cue → start-migration?: The calc-migration-probability function increments migration-probability each day the cue is active, and an agent transitions to start-migration? = true stochastically when random-float 1 <= migration-probability. This produces a spread of entry dates that can used for model evaluation.

18.3 Implementation in NetLogo

The P-MEM implementation builds directly on the GoFish behavioral library. The complete source code, input data, and documentation are archived at https://doi.org/10.5281/ZENODO.19483469 and the repository is documented at https://vmahan1998.github.io/GoFish/. The code shown here is the operational model; all nls files are used verbatim from the GoFish library.

18.3.1 File includes

18.3.2 Setup

18.3.3 The penobscot-setup procedure — full site-specific

18.3.4 The go procedure

18.3.5 The penobscot-go procedure — full time step sequence

18.3.6 What to observe

The P-MEM produces outputs across three categories:

  • Migration timing and passage counts: Compare alewives-on-line-daily-total-landward against observed fish passage data. The stochastic migration probability ramp should produce a realistic spread of entry dates peaked in late April–May.
  • Behavioral state dynamics: Plot the proportions of agents in STST (selective-tidal-transport?), foraging (foraging?), landward migration (landward-migration?), and at destination (at-destination?) over time. These proportions shift across the tidal cycle and across the migration season, illustrating how behavior reorganizes contaminant exposure opportunity.
  • Exposure pathway dominance: Compare mean [hg-uptake-risk] of alewives (branchial, gill-contact exposure) against mean [hg-foraging-total] of alewives (particulate ingestion) across predation scenarios. P-MEM shows that predation pressure shifts which pathway dominates individual cumulative burden.
  • Spatial exposure patterns: The Mercury Risk Explorer shows cumulative hg-exp-risk-total-alewife and mehg-exp-risk-total-alewife aggregated across patches, revealing which reaches of the estuary accumulate the most contaminant interaction across scenarios.

18.4 Processing in R

The R implementation of P-MEM is an analytical companion to the NetLogo model rather than a direct translation. Because P-MEM requires spatially explicit GIS data and hourly-resolution empirical hydrodynamic time series, the R code focuses on post-processing model outputs exported by NetLogo. Three distinct output streams are processed: temporal profiles (per-agent exposure metrics over time), agent-level space profiles (individual movement and exposure tracked through space across hours), and population-level patch outputs (cumulative spatial summaries converted to georeferenced rasters). The complete analysis pipeline is available at https://vmahan1998.github.io/GoFish/ and archived with the model at https://doi.org/10.5281/ZENODO.19483469.

18.4.1 Output file types

File type Naming pattern One row per
Agent — alewives results_alewives_<scenario>_mig_test_<run>_<month>.csv agent × export tick
Agent — striped bass results_stripedbass_<scenario>_mig_test_<run>_<month>.csv agent × export tick
Daily totals results_daily_<stamp>_<run>.csv simulation day
Patch-level results_patches_<scenario>_mig_test_<run>_ALL.csv water patch

18.4.2 Loading output files

library(data.table)

base_dir   <- "E:/Chapter 4 Outputs"
scenarios  <- c("none", "low", "base", "high")
runs       <- 1:3
months_use <- c("April", "May", "June", "July", "August", "September", "October")

risk_metrics <- c(
  "mehg_exposure_duration", "mehg_exposure_total",
  "mehg_foraging_total",    "mehg_total",
  "mehg_uptake_risk",       "mehg_foraging_undigested",
  "landward_migration",     "seaward_migration"
)

# Boolean handler — normalizes logical, numeric, and string TRUE/FALSE encodings
bool01 <- function(x) {
  if (is.logical(x)) return(as.integer(x))
  if (is.numeric(x)) return(as.integer(x != 0))
  as.integer(tolower(trimws(as.character(x))) %in% c("true","t","1","yes","y"))
}

# Force continuous metric columns to numeric (avoids mixed-type melt warnings)
coerce_numeric <- function(dt, vars) {
  vars <- intersect(vars, names(dt))
  for (v in vars) set(dt, j = v, value = suppressWarnings(as.numeric(dt[[v]])))
  invisible(dt)
}

build_agent_index <- function(base_dir, species_prefix, scenarios, runs, months_use) {
  idx <- CJ(scenario = scenarios, run = runs, month = months_use)
  idx[, file := file.path(base_dir,
    paste0(species_prefix, "_", scenario, "_mig_test_", run, "_", month, ".csv"))]
  idx[, exists := file.exists(file)]
  idx[exists == TRUE]
}

prey_files <- build_agent_index(base_dir, "results_alewives",    scenarios, runs, months_use)
pred_files <- build_agent_index(base_dir, "results_stripedbass", scenarios, runs, months_use)

18.4.3 Datetime conversion

Each agent file records day, hour, and minute relative to the simulation calendar (DOY 91 = April 1, 2023). The helper below converts these to POSIXct for time-series alignment across months and runs.

make_datetime_from_dayhm <- function(day, hour, minute,
                                     year = 2023, tz_use = "UTC") {
  base <- as.POSIXct(sprintf("%d-01-01 00:00:00", year), tz = tz_use)
  base + (as.integer(day) - 1L) * 86400 +
         as.integer(hour) * 3600 +
         as.integer(minute) * 60
}

make_datetime_from_ticks <- function(ticks,
  start_time = as.POSIXct("2023-04-01 00:00:00", tz = "UTC"),
  tick_minutes = 5) {
  start_time + as.numeric(ticks) * tick_minutes * 60
}

18.4.4 Temporal profiles — per-agent exposure metrics over time

Temporal profiles capture how exposure metrics accumulate across the season for each species and scenario. Each agent file is streamed one at a time; within each file the last record per agent per hour is retained (state metrics are cumulative), then averaged across agents per hour per run. A mean ± 95% CI is then computed across the three replicate runs per scenario. An incremental mehg_exposure_duration_delta column is derived by differencing consecutive hourly values per agent, capturing the rate of new high-exposure ticks rather than the running total.

stream_time_profiles <- function(file_df, species_label,
                                 metrics      = risk_metrics,
                                 months_use   = months_use,
                                 tick_minutes = 5,
                                 start_time   = as.POSIXct("2023-04-01", tz = "UTC"),
                                 gc_every     = 3L) {

  file_df        <- as.data.table(file_df)[month %in% months_use]
  if (nrow(file_df) == 0) return(data.table())
  ticks_per_hour <- as.integer(60 / tick_minutes)
  select_cols    <- unique(c("id", "ticks", "day", metrics))
  out_list <- vector("list", nrow(file_df))

  for (i in seq_len(nrow(file_df))) {
    dt <- fread(file_df$file[i], select = select_cols, showProgress = FALSE)
    if (nrow(dt) == 0) next
    setDT(dt)

    for (v in c("landward_migration","seaward_migration"))
      if (v %in% names(dt)) dt[, (v) := bool01(get(v))]

    dt[, `:=`(ticks = as.numeric(ticks), id = as.integer(id))]
    dt[, hour_index := as.integer(floor(ticks / ticks_per_hour))]
    setorder(dt, id, ticks)

    # Last record per agent per hour — state metrics are cumulative
    dt_hour <- dt[, .SD[.N], by = .(id, hour_index)]
    coerce_numeric(dt_hour, setdiff(metrics, c("landward_migration","seaward_migration")))

    # Derive incremental exposure-duration delta per agent across hours
    if ("mehg_exposure_duration" %in% names(dt_hour)) {
      setorder(dt_hour, id, hour_index)
      dt_hour[, dur_prev := shift(mehg_exposure_duration, 1L), by = id]
      dt_hour[, mehg_exposure_duration_delta :=
                  pmax(mehg_exposure_duration - dur_prev, 0)]
      dt_hour[is.na(dur_prev), mehg_exposure_duration_delta := 0]
      dt_hour[, dur_prev := NULL]
    }

    dt_hour[, datetime := start_time + hour_index * 3600]
    dt_hour[, `:=`(run = file_df$run[i], scenario = file_df$scenario[i])]

    out_list[[i]] <- melt(dt_hour,
      id.vars      = c("run","scenario","id","datetime","hour_index"),
      measure.vars = intersect(c(metrics,"mehg_exposure_duration_delta"), names(dt_hour)),
      variable.name = "metric", value.name = "value",
      variable.factor = FALSE)[is.finite(value)]

    rm(dt, dt_hour)
    if (i %% gc_every == 0) gc()
  }

  acc <- rbindlist(out_list, use.names = TRUE, fill = TRUE)

  # Mean across agents per run/scenario/hour → CI across runs
  run_means <- acc[, .(mean_run = mean(value, na.rm = TRUE), n = uniqueN(id)),
                    by = .(run, scenario, metric, datetime, hour_index)]

  out <- run_means[,
    .(n_runs  = uniqueN(run),
      n_total = max(n),
      mean    = mean(mean_run, na.rm = TRUE),
      sd      = sd(mean_run,   na.rm = TRUE)),
    by = .(scenario, metric, datetime, hour_index)]
  out[, `:=`(se = sd / sqrt(pmax(n_runs,1L)),
             ci_low  = mean - 1.96 * sd / sqrt(pmax(n_runs,1L)),
             ci_high = mean + 1.96 * sd / sqrt(pmax(n_runs,1L)),
             species = species_label)]
  setorder(out, metric, scenario, datetime)
  out[]
}

prey_profiles_time <- stream_time_profiles(prey_files, "Alewives",     metrics = risk_metrics)
pred_profiles_time <- stream_time_profiles(pred_files, "Striped bass", metrics = risk_metrics)
profiles_time_dt   <- rbindlist(list(prey_profiles_time, pred_profiles_time),
                                use.names = TRUE, fill = TRUE)

saveRDS(profiles_time_dt, "temporal_risk_profiles.rds", compress = "xz")
rm(prey_profiles_time, pred_profiles_time, profiles_time_dt); gc()

18.4.5 Agent-level space profiles — individual movement through space over time

Space profiles track where agents are each hour and what exposure metric values they carry at that location. Unlike the patch-level outputs (which aggregate the full population), these are derived from the agent files and preserve the link between individual position and individual exposure state. Each agent’s end-of-hour location is binned into spatial cells; hourly cell means are computed per run, then summarised across runs with CI. This produces a space × time × metric × scenario table that supports animation and longitudinal spatial analysis of how exposure accumulates as agents move through the estuary.

stream_space_profiles <- function(file_df, species_label,
                                  metrics       = risk_metrics,
                                  months_use    = months_use,
                                  tick_minutes  = 5,
                                  start_time    = as.POSIXct("2023-04-01", tz = "UTC"),
                                  px_bin_width  = 1,
                                  py_bin_width  = 1,
                                  x_bin_width   = 5,
                                  y_bin_width   = 5,
                                  gc_every      = 3L) {

  file_df        <- as.data.table(file_df)[month %in% months_use]
  if (nrow(file_df) == 0) return(data.table())
  ticks_per_hour <- as.integer(60 / tick_minutes)
  add_delta      <- "mehg_exposure_duration" %in% metrics
  metrics_out    <- if (add_delta) unique(c(metrics, "mehg_exposure_duration_delta")) else metrics
  select_cols    <- unique(c("id","ticks","day","pxcor","pycor","xcor","ycor", metrics))
  out_list <- vector("list", nrow(file_df))
  out_i    <- 0L

  for (i in seq_len(nrow(file_df))) {
    dt <- fread(file_df$file[i], select = select_cols, showProgress = FALSE)
    if (nrow(dt) == 0) next
    setDT(dt)

    for (v in c("landward_migration","seaward_migration"))
      if (v %in% names(dt)) dt[, (v) := bool01(get(v))]

    dt[, `:=`(ticks = as.numeric(ticks), id = as.integer(id))]
    dt[, hour_index := as.integer(floor(ticks / ticks_per_hour))]
    setorder(dt, id, ticks)

    # End-of-hour record per agent — captures where the agent ended up
    dt_end <- dt[, .SD[.N], by = .(id, hour_index)]
    coerce_numeric(dt_end, setdiff(metrics, c("landward_migration","seaward_migration")))

    # Incremental exposure-duration delta per agent
    if (add_delta && "mehg_exposure_duration" %in% names(dt_end)) {
      setorder(dt_end, id, hour_index)
      dt_end[, dur_prev := shift(mehg_exposure_duration, 1L), by = id]
      dt_end[, mehg_exposure_duration_delta :=
                  pmax(mehg_exposure_duration - dur_prev, 0)]
      dt_end[is.na(dur_prev), mehg_exposure_duration_delta := 0]
      dt_end[, dur_prev := NULL]
    }

    # Spatial bins from end-of-hour agent position
    dt_end[, `:=`(
      px_bin = as.integer(floor(as.numeric(pxcor) / px_bin_width)),
      py_bin = as.integer(floor(as.numeric(pycor) / py_bin_width)),
      x_bin  = as.integer(floor(as.numeric(xcor)  / x_bin_width)),
      y_bin  = as.integer(floor(as.numeric(ycor)  / y_bin_width))
    )]

    # Hourly cell means across agents (population mean per spatial bin per hour)
    hour_wide <- dt_end[,
      c(.(ticks = mean(ticks,na.rm=TRUE), day = mean(day,na.rm=TRUE),
          pxcor = mean(pxcor,na.rm=TRUE), pycor = mean(pycor,na.rm=TRUE),
          xcor  = mean(xcor, na.rm=TRUE), ycor  = mean(ycor, na.rm=TRUE)),
        lapply(.SD, function(x) mean(as.numeric(x), na.rm = TRUE))),
      by = .(hour_index, px_bin, py_bin, x_bin, y_bin),
      .SDcols = intersect(metrics_out, names(dt_end))
    ]

    if (nrow(hour_wide) == 0) { rm(dt, dt_end, hour_wide); next }

    hour_wide[, datetime := start_time + hour_index * 3600]
    hour_wide[, `:=`(run = file_df$run[i], scenario = file_df$scenario[i],
                     px_bin_center = (px_bin + 0.5) * px_bin_width,
                     py_bin_center = (py_bin + 0.5) * py_bin_width,
                     x_bin_center  = (x_bin  + 0.5) * x_bin_width,
                     y_bin_center  = (y_bin  + 0.5) * y_bin_width)]

    hour_long <- melt(hour_wide,
      id.vars = c("run","scenario","datetime","hour_index","ticks","day",
                  "pxcor","pycor","xcor","ycor",
                  "px_bin","py_bin","x_bin","y_bin",
                  "px_bin_center","py_bin_center","x_bin_center","y_bin_center"),
      measure.vars  = intersect(metrics_out, names(hour_wide)),
      variable.name = "metric", value.name = "mean_t",
      variable.factor = FALSE)[is.finite(mean_t)]

    if (nrow(hour_long) > 0) { out_i <- out_i + 1L; out_list[[out_i]] <- hour_long }
    rm(dt, dt_end, hour_wide, hour_long)
    if (i %% gc_every == 0) gc()
  }

  if (out_i == 0L) return(data.table())
  acc <- rbindlist(out_list[seq_len(out_i)], use.names = TRUE, fill = TRUE)

  # Run-level mean per spatial bin × hour × metric
  run_cell <- acc[,
    .(mean_run = mean(mean_t, na.rm = TRUE),
      ticks = mean(ticks,na.rm=TRUE), day = mean(day,na.rm=TRUE),
      pxcor = mean(pxcor,na.rm=TRUE), pycor = mean(pycor,na.rm=TRUE),
      xcor  = mean(xcor, na.rm=TRUE), ycor  = mean(ycor, na.rm=TRUE)),
    by = .(run, scenario, datetime, hour_index,
           px_bin, py_bin, x_bin, y_bin,
           px_bin_center, py_bin_center, x_bin_center, y_bin_center, metric)
  ]

  # CI across runs
  out <- run_cell[,
    .(n_runs = uniqueN(run),
      mean   = mean(mean_run, na.rm = TRUE),
      sd     = sd(mean_run,   na.rm = TRUE),
      ticks  = mean(ticks,na.rm=TRUE), day = mean(day,na.rm=TRUE),
      pxcor  = mean(pxcor,na.rm=TRUE), pycor = mean(pycor,na.rm=TRUE),
      xcor   = mean(xcor, na.rm=TRUE), ycor  = mean(ycor, na.rm=TRUE)),
    by = .(scenario, datetime, hour_index,
           px_bin, py_bin, x_bin, y_bin,
           px_bin_center, py_bin_center, x_bin_center, y_bin_center, metric)
  ]
  out[, `:=`(se = sd / sqrt(pmax(n_runs,1L)),
             ci_low  = mean - 1.96 * sd / sqrt(pmax(n_runs,1L)),
             ci_high = mean + 1.96 * sd / sqrt(pmax(n_runs,1L)),
             species = species_label)]
  setorder(out, metric, scenario, datetime, py_bin, px_bin)
  out[]
}

prey_profiles_space <- stream_space_profiles(prey_files, "Alewives",     metrics = risk_metrics)
pred_profiles_space <- stream_space_profiles(pred_files, "Striped bass", metrics = risk_metrics)
profiles_space_dt   <- rbindlist(list(prey_profiles_space, pred_profiles_space),
                                 use.names = TRUE, fill = TRUE)

saveRDS(profiles_space_dt, "spatial_risk_profiles.rds", compress = "xz")
rm(prey_profiles_space, pred_profiles_space, profiles_space_dt); gc()

18.4.6 Population-level spatial outputs — patch summaries and rasters

Patch outputs are population-level: each row in a patch file records cumulative counts and risk totals accumulated across all agents that visited that patch during a simulation run. These are combined across runs and converted to georeferenced rasters for use in the Mercury Risk Explorer and for spatial analysis in GIS tools.

library(terra)

patch_colnames <- c(
  "pxcor","pycor","forage_visits","forager_count","forage_species",
  "prey_eaten_in_patch","tidal_transport_in_patch",
  "ticks_spent_alewife","visits_by_alewife",
  "ticks_spent_stripedbass","visits_by_stripedbass",
  "hg_foraging_risk_alewife","mehg_foraging_risk_alewife",
  "hg_foraging_risk_stripedbass","mehg_foraging_risk_stripedbass",
  "hg_foraging_risk_total_alewife","mehg_foraging_risk_total_alewife",
  "hg_foraging_risk_total_stripedbass","mehg_foraging_risk_total_stripedbass",
  "hg_exp_risk_alewife","mehg_exp_risk_alewife",
  "hg_exp_risk_stripedbass","mehg_exp_risk_stripedbass",
  "hg_exp_risk_total_alewife","mehg_exp_risk_total_alewife",
  "hg_exp_risk_total_stripedbass","mehg_exp_risk_total_stripedbass"
)

patch_index <- CJ(scenario = scenarios, run = runs)
patch_index[, file := file.path(base_dir,
  paste0("results_patches_", scenario, "_mig_test_", run, "_ALL.csv"))]
patch_index[, exists := file.exists(file)]
patch_index <- patch_index[exists == TRUE]

patch_dt <- rbindlist(lapply(seq_len(nrow(patch_index)), function(i) {
  dt <- fread(patch_index$file[i], header = FALSE)
  setnames(dt, patch_colnames)
  dt[, `:=`(scenario = patch_index$scenario[i], run = patch_index$run[i])]
}), fill = TRUE)

# Cumulative risk = branchial exposure + foraging exposure
patch_dt[, `:=`(
  cum_mehg_risk_alewife     = mehg_exp_risk_total_alewife + mehg_foraging_risk_total_alewife,
  cum_mehg_risk_stripedbass = mehg_exp_risk_total_stripedbass + mehg_foraging_risk_total_stripedbass
)]

# Sum within run, then mean ± SD across runs per scenario
patch_run <- patch_dt[,
  .(cum_mehg_risk_alewife           = sum(cum_mehg_risk_alewife,          na.rm = TRUE),
    ticks_spent_alewife             = sum(ticks_spent_alewife,            na.rm = TRUE),
    mehg_exp_risk_total_alewife     = sum(mehg_exp_risk_total_alewife,    na.rm = TRUE),
    mehg_exp_risk_total_stripedbass = sum(mehg_exp_risk_total_stripedbass,na.rm = TRUE)),
  by = .(scenario, run, pxcor, pycor)
]

patch_summary <- patch_run[,
  .(n_runs = uniqueN(run),
    cum_mehg_risk_alewife_mean           = mean(cum_mehg_risk_alewife,          na.rm = TRUE),
    cum_mehg_risk_alewife_sd             = sd(cum_mehg_risk_alewife,            na.rm = TRUE),
    ticks_spent_alewife_mean             = mean(ticks_spent_alewife,            na.rm = TRUE),
    mehg_exp_risk_total_alewife_mean     = mean(mehg_exp_risk_total_alewife,    na.rm = TRUE),
    mehg_exp_risk_total_stripedbass_mean = mean(mehg_exp_risk_total_stripedbass,na.rm = TRUE)),
  by = .(scenario, pxcor, pycor)
]

patch_summary[, minutes_spent_alewife_mean := ticks_spent_alewife_mean * 5]

# Convert NetLogo patch coordinates to geographic coordinates
shapefile    <- vect("inputs/studyarea.shp")
if (!terra::is.lonlat(shapefile)) shapefile <- project(shapefile, "EPSG:4326")
e            <- ext(shapefile)
patch_width  <- (xmax(e) - xmin(e)) / 200
patch_height <- (ymax(e) - ymin(e)) / 350

patch_summary[, `:=`(
  lon = xmin(e) + (pxcor + 0.5) * patch_width,
  lat = ymin(e) + (pycor + 0.5) * patch_height
)]

# Raster template matching the NetLogo world extent
r_template <- rast(ncols = 200, nrows = 350,
                   xmin = xmin(e), xmax = xmax(e),
                   ymin = ymin(e), ymax = ymax(e),
                   crs  = "EPSG:4326")

make_raster <- function(dt, value_col, r_template) {
  pts <- vect(dt[, .(lon = as.numeric(lon), lat = as.numeric(lat),
                     v   = as.numeric(get(value_col)))][is.finite(v)],
              geom = c("lon","lat"), crs = "EPSG:4326")
  r <- rasterize(pts, r_template, field = "v", fun = "mean", background = NA)
  r[r <= 0] <- NA
  r
}

output_dir <- file.path(base_dir, "Processed_Rasters")
dir.create(output_dir, showWarnings = FALSE, recursive = TRUE)

vars_to_export <- c(
  "cum_mehg_risk_alewife_mean",
  "minutes_spent_alewife_mean",
  "mehg_exp_risk_total_alewife_mean",
  "mehg_exp_risk_total_stripedbass_mean"
)

for (scen in scenarios) {
  dt_scen <- patch_summary[scenario == scen]
  for (v in vars_to_export) {
    writeRaster(make_raster(dt_scen, v, r_template),
      file.path(output_dir, paste0(scen, "_", v, ".tif")),
      overwrite = TRUE)
  }
}

18.5 Applied Potential for Decision Making

P-MEM was designed not only as a research tool but as a framework for translating simulation outputs into actionable information for environmental managers, restoration practitioners, and community stakeholders. The Mercury Risk Explorer is the interactive decision-support interface built on P-MEM outputs, allowing users to explore model results without running the simulation directly.

18.5.2 What the outputs show

The tab provides three linked views that together illustrate how behavior mediates exposure:

Spatial exposure maps show cumulative mehg_exp_risk_total (gill exposure) and mehg_foraging_risk_total (foraging exposure) aggregated across patches and averaged across replicate runs for each scenario.

Temporal risk profiles show how mean cumulative exposure accumulates through the season, with 95% confidence intervals across replicate runs.

Behavioral state time series show the proportion of agents in each state (STST passive drift, active migration, foraging, at destination) as a function of time.

18.5.3 Decision-relevant outputs

Applied ABMs are most valuable when they are designed from the outset around questions that managers cannot answer with static spatial analysis alone. Three categories of decision-relevant questions recur across environmental management contexts, and the design choices made throughout this book (spatially explicit environments, state-dependent behavioral submodels, and physiological feedbacks) are what make an ABM capable of addressing them.

  • Where is risk highest and when? Spatially and temporally explicit ABMs simulate when individual agents are in high-risk locations, not just whether suitable habitat overlaps with a hazard. Because every agent carries its own physiological and behavioral state through time, the model identifies which combinations of location, timing, life-history stage, and behavioral mode produce the highest cumulative risk — information invisible to static exposure-potential or habitat suitability analyses.

  • How does a stressor reorganize behavior and exposure? ABMs allow stressors to be represented as behavioral interactions rather than fixed mortality or exposure rates, so the outcome emerges from the accumulated consequences of individual decisions across time. Models designed with explicit, traceable function dependencies can isolate which behavioral pathway is responsible for a given outcome, making the mechanism transparent to managers and stakeholders.

  • What outcomes follow from a physical or management intervention? Because submodels are coupled through shared state variables, a change to the environment propagates through the behavioral and physiological chain the same way it would in the real system and that full propagation chain is traceable through the function dependency table. This traceability is what makes model predictions credible and actionable rather than descriptive.

These outputs illustrate how agent-based models can be implemented to support applied decision making across a range of environmental management contexts. The questions addressed here represent a general class of problems that arise whenever managers need to understand not just where a hazard exists, but how organisms interact with it through movement, physiology, and social behavior. Process-based behavioral models produce qualitatively different management insights than static habitat suitability or exposure-potential analyses because they simulate how individual decisions aggregate into population-level patterns across space and time. The modular design of the GoFish Library means that the same architecture used here can be adapted to other species, other stressors, and other spatial domains by substituting the relevant environmental forcing, species parameters, and outcome metrics while preserving the core behavioral and physiological logic.
